Description
Mercusys AC1200 Dual Band Wireless Router. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Networking standards: IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3u, Ethernet LAN data rates: 10,100 Mbit/s. Security algorithms: WPA-PSK,WPA2-PSK. Product type: Tabletop router, Product colour: Black. Antenna type: External, Antenna gain level (max): 5 dBi
Faster Access to a More Colorful Life
AC1200 Dual Band Wireless Router
AC12
Blazing-Fast Everyday Wi-Fi
Complying with the powerful 802.11ac standard, AC12 delivers a blazing-fast Wi-Fi speed of up to 1200Mbps, which is 3x faster than the speed of the previous 802.11n standard. AC12 lets your home devices achieve their optimal Wi-Fi performance. It is the superior choice for providing faster, stronger Wi-Fi over your home or office.
Concurrent Dual Band Connections
AC12 provides simultaneous dual-band Wi-Fi signals. The 2.4GHz band delivers 300Mbps Wi-Fi for everyday activities like surfing the internet and sending emails. The crystal 5GHz band reaches 867Mbps so you can game online and stream in HD simultaneously. Both bands work at the same time to meet the needs of multiple tasks on different devices.
Strong Signal,
Great Coverage
Four external 5dBi antennas powered with advanced antenna technology provide users with larger wireless coverage and wireless signal intensity throughout your large home or office, making weak, dropped connections a thing of the past.
Superior Online Experience with IPv6 & IPTV
Compatible with IPv6, AC12 allows you to enjoy IPv6 services provided by ISP
and visit IPv6 websites.
IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV
streaming for high network efficiency and superior online experience.
Easy Three-Step Installation
With no need for complicated configuration, you can simply follow the step-by-step instructions on the intuitive webpage to set up your AC12 in minutes.
- 1. Create a unique login password
- 2. Choose your internet service and enter the required information
- 3. Set your wireless network name ( SSID ) and password
| Dimensions (W X D X H) |
222mm x 140mm x 32mm |
| External Power Supply |
9VDC/0.85A |
| Antenna Type |
4 x 5dBi omni directional antennas |
| Signal Rate |
11ac: Up to 867Mbps (Dynamic) |
| 11n: Up to 300Mbps (Dynamic) |
| 11g: Up to 54Mbps (Dynamic) |
| 11b: Up to 11Mbps (Dynamic) |
| Button |
Reset button |
| Wireless Standards |
IEEE 802.11ac、IEEE 802.11n、IEEE 802.11g、IEEE 802.11b、IEEE 802.3、IEEE 802.3u |
| Frequency |
2.390 ~ 2.4835GHz |
| 5.150 ~ 5.825GHz |
| Reception Sensitivity |
11b CCK 1 -96 |
| 11g OFDM 6 -93 |
| 11n HT20 MCS7 -73 |
| 11n HT40 MCS7 -70 |
| 11a OFDM 6 -92 |
| 11ac VHT20 MCS8 -68 |
| 11ac VHT40 MCS9 -64 |
| 11ac VHT80 MCS9 -60 |
| Interfaces |
4 10/100Mbps LAN ports |
| 1 10/100Mbps WAN port |
| Certifications |
CE, ROHS |
| Package Contents |
AC1200 Dual Band Wireless Router |
| Power adapter |
| Quick installation guide |
| Ethernet cable |
| Environment |
Operating temperature: 0⁰C ~ 40⁰C (32⁰F ~ 104⁰F) |
| Storage temperature: -40⁰C ~ 70⁰C (-40⁰F ~ 158⁰F) |
| Operating humidity: 10% ~ 90%, non-condensing |
| Storage humidity: 5% ~ 90%, non-condensing |
| Transmission Power |
<20dBm |
| Wireless Security |
WPA-PSK / WPA2-PSK |
| Wireless Functions
|
WDS bridge |
| WAN Type |
Dynamic IP/Static IP/PPPoE |
| Management |
Access control |
| Local management |
| Remote management |
| DHCP |
Server |
| Port Forwarding |
Virtual server, UPnP, DMZ |
| Dynamic DNS |
Oray |
| Firewall Security |
IP and MAC address binding |
| Protocols |
IPv4 |
| Guest Network |
2.4GHz guest network |
